6kW 1P LV Hybrid Inverter
Category
Dyness 6kW 1P LV Hybrid Inverter
1000 In Stock
| Branch | SED JHB |
|---|---|
| Category | |
| Product Code | INV-DYNESS-6KW-LV-1P |
| Manufacturer Code | Dyness 6KW inverter |
| Description | 6kW 1P LV Hybrid Inverter |
Additional information
| Inverter Type | Hybrid Inverter |
|---|---|
| Phase Type | Single Phase (1PH) |
| AC Output Power (W) | 12 800 |
| Max. AC Output Power (W) | 12 800 |
| AC Output Current (A) | 27.3/26.1 |
| Max. AC Output Current (A) | 30 |
| Battery Voltage (V) | 330 |
| Battery Voltage Range (V) | 90 - 520 |
| Battery Max. Charge Current (A) | 112 |
| Battery Max. Discharge Current (A) | 112 |
| Battery Types | Lead-acid or Lithium-ion |
| MPPT trackers/strings | 2/2 |
| MPPT Max. Input Power (W) | 5000 |
| MPPT Max. Voltage (V) | 600 |
| MPPT Voltage Range (V) | 90 - 520 |
| MPPT Input Current (A) | 16 |
| MPPT Max. Input Current (Isc) | 16 |
| *Warranty Period (Years) | 10 |
| IP Rating | IP66 |
| Weight (Kg) | 24 |
| Dimentions (LxWxH) mm | 205 x 406 x 560 |
| Communication | RS485; CAN, LAN, WiFi |
*Refer to manufacturer warranty specifications and limitations
