Jinko 555W P Type half-cell Mono
Jinko 555W P Type half-cell Mono
72 In Stock
| Branch | SED JHB |
|---|---|
| Category | |
| Product Code | PAN-JINKO-JKM555M-72HL4-(V) |
| Manufacturer Code | JKM555M-72HL4-(V) |
| Description | Jinko 555W P Type half-cell Mono |
Additional information
| Maximum Power (W) | 555 |
|---|---|
| Module Frame (Colour) | Anodized Aluminium Alloy |
| Open Circuit Voltage (Voc) | 56.6 |
| Maximum Power Voltage (Vmp) | 41.95 |
| Maximum Series Voltage (Vdc) | 1500 |
| Short Circuit Current (Isc) | 11.77 |
| Maximum Power Current (Imp) | 14.13 |
| Module Efficiency (%) | 21.68 |
| *Warranty Period (Years) | 12 |
| *Linear Output Guarantee (Years) | 30 |
| IP Rating | IP68 Rated |
| Weight (Kg) | 32.0 |
| Height (mm) | 30 |
| Width (mm) | 1134 |
| Length (mm) | 2278 |
| Connector Type | TUV 1 x 4.0mm Squared |
| Cable Length (mm) | 400/200/customized |
| Pallet Quantity (Modules) | 36 |
*Refer to manufacturer warranty specifications and limitations
